Four sliding guides on axis Z
+ With the four-rail design on axis Z, the rigidity of the machine is higher and the cutting performance is greatly increased. (For HSA2212 / 3212/2215 four rails are optional, the rest of the machines are standard.)
Three slideways on axis X (HSA-X28 / HSA-X36)
+ The design of three slide guides on axis X can withstand the cutting torque, the rigidity can be increased by 50%. In addition, Max. table load can be up to 30000 Kg.
reduced vibration during cutting due to new force flow design
+ New ramp beam design redirects 45 ° cutting force into columns, significantly reducing vibration by efficiently transmitting force flow.
Maximum Transmission Power Improves Positioning Accuracy
+ Our patented X- and Y-axis For ball screws ensure rpmimum power transmission. loss as well as rpmimization of sag problems For improved processing accuracy.
Nitrogen meter
+ Due to the nitrogen back pressure design on axis Z, the noise of the hydraulic unit can be reduced up to 72dB, and the oil tank temperature can be reduced up to 35 ℃. In addition, the accelerated travelaxis Z can be increased up to 16 m / rpm.
